| S.NO | DESCRIPTION |
UNIT | DIMENSION |
|---|---|---|---|
| A | HAMMER LENGTH W/O BIT |
MM | 984.5 |
| B | HAMMER LENGTH WITH BIT |
MM | 1088.5 |
| C | HAMMER OUTER DIAMETER |
MM | 148 |
| D | HOLE SIZE |
MM | 165 & ABOVE |
| E | WRENCH SIZE A/F |
MM | 90 |
| F | TOP SUB(COUPLER) THREAD CONNECTION |
MM | 2 7/8 API IF |
| G | SUITABLE SHANK |
- | M6 SHANK |
| H | PISTON WEIGHT |
KGS | 17 |
| I | HAMMER WEIGHT |
KGS | 90 |
| J | CYLINDER BORE |
MM | 120.5 |
| S.NO | Operating pressure (OP) in PSI |
Air Consumption (AC) in CFM |
|---|---|---|
| 1 | 150 |
360 |
| 2 | 250 |
660 |
